Introduction

The Ultralight N17 is a RepRapFirmware and Klipper compatible expansion board, developed in collaboration with Millennium Machines.

It uses CAN(-FD) to communicate with RepRapFirmware or Klipper (or anything else for that matter), allowing you to control a single bipolar stepper motor. It exposes one input port for an endstop (3 pin, PH 2.0) and one output port for any auxiliary device, e.g. a fan (2 pin, PH 2.0).

This page covers the r1.5 version of the board.

Quick Start

1. Review the Pinout - Understand the connections before wiring
2. Configure Jumpers - Set up VIO, CAN mode, and termination
3. Mount to Motor - Install on your NEMA17 motor
4. Configure Firmware - Set up RRF or Klipper
5. Learn - Detailed technical information

Purchase

Buy the Ultralight N17 on Tindie.

Thanks
